The E-MU 0404 features:

	24-bit, 96kHz converters that deliver 111dB (A/D) and 116dB (D/A) SNR and Dynamic Range
	Connectivity with 1/4" analog I/O, optical and coaxial 24/96 S/PDIF I/O, and MIDI I/O for seamless integration with your entire studio
	E-DSP 32-bit Multi-effects Processor offers you over 16 simultaneous hardware-accelerated studio, grade effects with no CPU overhead , plug-in architecture allows you to add new effects as needed
	32 Channels of zero latency Hardware Mixing/ Monitoring with flexible virtual patchbay ,no external mixer needed
	Full compatibility with most popular audio/sequencer applications with ultra-low latency WDM, DirectSound and ASIO 2.0 Drivers
	Software studio package

I/O Configuration:

	Two 1/4" Analog Inputs
	Optical 24-bit/96kHz S/PDIF In/Out (switchable to AES/EBU)
	Coaxial 24-bit/96kHz S/PDIF In/Out (switchable to AES/EBU)
	MIDI In/Out

E-DSP Hardware-accelerated Effects, Mixing and Monitoring:

E-MU's Digital Audio Systems feature the E-DSP chipset, which features a hardware-accelerated effects processor with over 20 effects plug-ins (over 500 presets). This effects architecture is fully expandable, allowing you to add more effect plug-ins to your system as needed. E-DSP also provides zero-latency, hardware-based mixing and monitoring via the included PatchMix DSP mixer, delivering flexibility in routing audio between all of your physical and virtual (ASIO/WDM) inputs and outputs.No external mixer needed.

All Digital Audio Systems ship with the following Effects Plug-ins:

1-Band Para EQ 1-Band Shelf EQ 3-Band EQ 4-Band EQ Auto-Wah Chorus Compressor Distortion Distortion Freq Shifter Leveling Amp Mono Delay 100 Mono Delay 3000 Stereo Delay 100 Stereo Delay 1500 Phase Shifter Rotary Speaker Simulator Stereo Reverb Vocal Morpher

Listen to ... DAS 0404 Effects Plug-ins

Acoustic Guitar (Chorus/Reverb) Acoustic Guitar.mp3

Bass Guitar (Compression/EQ) Bass Guitar.mp3

Drum Kit (Compression/EQ) Drum Kit.mp3

Electric Guitar (Distortion/EQ/Speaker Simulator/Delay/Reverb) Electric Guitar.mp3

Electric Piano (Phase Shifter/Reverb)  Electric Piano.mp3

Fat Synthesizer (Flanger/Delay/Reverb)  Fat Synthesizer.mp3

Soprano Sax (Reverb) Soprano Sax.mp3

Synthesizer Bass (Chorus/Reverb) Synthesizer Bass.mp3

Vocalist (EQ  /Delay/Reverb) Vocalist.mp3
